Question #73341
With 21 V applied, if R1 = 5 ohms, R2 = 35 ohms, and R3 = 14 ohms, what is the current of R2 if R1 is series connected with parallel circuit R2 and R3?
Options:
Answer:
With 21 V applied, if R1 = 5 ohms, R2 = 35 ohms, and R3 = 14 ohms, what is the current of R2 if R1 is series connected with parallel circuit R2 and R3 400 mA.
Question Screenshot
