Question #78908
If a bent tendon is required to balance a concentrated load W at the centre of the span L, the central dip h must be at least________________?
Options:
Answer:
If a bent tendon is required to balance a concentrated load W at the centre of the span L, the central dip h must be at least WL/4P.
Question Screenshot
